Dimensions: 100*76*66mm
Operating Temperature: -10℃~50℃
Accuracy Class: 1
Measuring Energy Range: 999999.9kWh
Phase: Three Phase
Model Number: DTS024
Max Operating Current: 80A - 99A
Rated Voltage: 230V
Power Supply: AC
Display Type: LCD
DIY Supplies: ELECTRICAL
Function：Only measure kwh
Current：100A
Specification
Model: DTS024
Voltage: AC230V/400V
Constant Pulse: 400imp / kWh
Power Consumption: ≤2W, 10VA
Display: LCD 6+1
Size: 3.97 X 2.99 X 2.55in
Accuracy of voltage: Class 1
Install way: Din Rail
MAX Current: 100A
Frequency: 50/60Hz
Operating Temperature: -20 ~ 50℃
