Dimensions: 98*72*65mm
Operating Temperature: -20 ℃~ 50℃
Accuracy Class: 1
Measuring Energy Range: 99999.99kwh
Phase: Three Phase
Model Number: DTS024M
Max Operating Current: 100A - 119A
Rated Voltage: 230V
Power Supply: AC
Display Type: LCD
Function1: RS485
Function2: V A HZ cos
Describe
It can directly and accurately measure AC active energy with a rated frequency of 50/60Hz. The LCD displays total active/reactive energy, input/output active/reactive energy, three-phase voltage, current, total/phase active power, total/phase power factor: frequency and other information. It has the characteristics of good reliability, small size, light weight, beautiful appearance, and flexible and convenient installation.
Specifications
1. 35mm DIN standard rail installation, in accordance with DINEN-50022 standard
2. High accuracy measurement of active energy, active energy level 1 and reactive energy level 2, or active energy level 0.5 and reactive energy level 2
3. LCD 5+2 bit display (99999.99kWh), without backlight
4. Passive pulse output, compliant with DIN43864 standard
5. LED indicator pulse output
6. Can quickly query various parameters and wake up the RS485 communication interface with backlight by pressing buttons on site, MODBUS communication protocol
7. Equipped with reactive energy metering, displaying functions such as current, voltage, power factor, etc
